Autel ITS600 CV is a wireless Android-based touchscreen tablet that offers full TPMS system diagnostics and sensor programming for commercial vehicles and trucks. The tablet features a 5.5″ display and a wireless VCI module for vehicle communication. Lifetime TPMS updates included! Updates are available for the entire lifetime of the device. Additionally, the Autel ITS600 CV is compatible with the TBE200 tire tread wear analysis tool (sold separately). By providing a wide range of tire-related features and functions, the ITS600 is the perfect choice for TPMS and vehicle servicing tasks. TPMS Functions: Full TPMS functionality for commercial vehicles (CV and TRUCK): inspection, diagnostics, relearn, and programming Activation, reading, and relearn of all known TPMS sensors Combined tractor and trailer interfaces – individual support, with display of up to 46 wheels and 12 axles Fast switching between tractor and trailer screens for comprehensive sensor and tire analysis Activation, relearn, and programming of Autel CVS-A01 sensors via a multifunction tabbed interface ECU diagnostics for complete TPMS status control with DTC description Reading and clearing DTCs from the ECU Programming of MX-Sensors, cloning original sensor IDs, or creating new random IDs Relearn of sensor positions Access to detailed TPMS-related procedures Standard Equipment: Autel ITS600 device Deutsch 6-pin and 9-pin adapters, UNI-4 DLC User manual USB cable Charger OBD plug

TEKNISET TIEDOT

WiFi USB 2.0, Type C Bluetooth Battery / Power Supply 3.8 V / 5000 mAh lithium-polymer;5 VDC; Dimensions 183.0 mm (7.2”) x 89.0 mm (3.5”) x 22.0 mm (0.87”) Protocols ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code,SAE-J1850 VPW, SAE-J1850 PWM, ISO11898 (Highspeed, Middlespeed,Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610,GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.66
